How To Root Samsung Galaxy Tab S5E Using Magisk Patched Image

Looking for a way to root Samsung Galaxy Tab S5E (SM-T720) ? Then you are the right place. To maximize its performance and get control of system files you can root your device. Magisk is the perfect way to root your Android device and here we share an easy method to install the Magisk on Samsung Galaxy Tab S5E (SM-T720). This article will help you to root Galaxy Tab S5E (SM-T720) with Magisk Patched Boot Image by following these steps below.

Some days ago Samsung launched their latest A-series smartphone and the Galaxy Tab S5E (SM-T720) is one of the good mid-range phones. After root Galaxy Tab S5E (SM-T720) you can get some extra benefits. Also, you can install many Magisk modules like Mod, font, theme to increase your device performance. But before starting to process backup of your device data, it wipes full storage and one thing warranty will void after rooting the device.

Way To Root Samsung Galaxy Tab S5E (SM-T720)

Here we share a complete guide to “Root Galaxy Tab S5E (SM-T720)” without TWRP recovery. Before starting process makes sure your device bootloader must be unlocked. First, we will create a patched boot.img using Magisk canary then flash this boot.img.tar using ODIN Tool to root. If you have Samsung Galaxy Tab S5E (SM-T720) and you want to install root your smartphone. Then read the full guide to make it easier.

Pre-requisites

Go to your settings ⇒ Developer options ⇒ tick the“ OEM Unlock ” checkbox
  • Download Required Files and Read Guide.

Download Samsung Galaxy Tab S5E (SM-T720) Root Files

Latest ODIN

Canary Patched Magisk

Guide to Root Samsung Galaxy Tab S5E (SM-T720) On Android Pie

  • Download stock firmware for your device. (Version should be similar on which your phone is running)
  • Then extract it and copy the AP tar file to your device.
  • Now install the ‘Canary Patched Magisk‘ apk on your device and open it.
  • In Magisk Manager, Open Settings ⇒ Patched Boot Output Format and select “.img.tar“.
  • After that back to Magisk home and select “Install ⇒ Install ⇒ select and patch file” option.

  • Now select the AP tar file. Magisk Manager will patch the whole firmware file and store the output to [Internal Storage]/Download/magisk_patched.tar.
  • Connect your device to the computer and copy the “magisk_patched.tar” on your desktop.
  • After that download Odin and extract Odin-v3.*.* and run Odin3 vx.xx.exe.
  • Then Switch Off your device.
  • Turn your device into Download Mode By (Power + Bixby + Volume Up).
Keep Pressing Volume Up to acknowledge the warning Then Phone Will Turn Download Mode
  • Again Connect your phone with PC via USB.
  • ODIN will detect your device.
  • Uncheck Auto Reboot from Option.
  • That is, check the AP Box, select the ‘magisk_patched.tar‘ file.
  • Like the Screenshot:

TWRP for Samsung Galaxy A6

  • Now click Start Button on ODIN to begin the installation process.
  • Once done you’ll see PASS! message on ODIN after that Press Power + Volume Down to exit download mode. As soon as the screen turns off, immediately press Power + Volume Up and hold Volume Up button until you see the stock recovery screen.
  • When you are in Stock Recovery mode select wipe data/factory reset to wipe the data of the device.
  • Now select “Reboot system now” and immediately press Volume Up ⇒ Bootloader warning ⇒ Release all buttons.
  • Install Magisk Manager APK again and open it. It will ask to install zip file, so install it and reboot the device.
  • That’s it now you can enjoy all the root features on your device.

If you have any problems do comment below. Also, for more updates on stuff like Mods, wallpapers, themes etc like our Facebook page.
