Guide To Unlock Bootloader Of Asus Zenfone 4 ZE554KL

Unlock Bootloader Of Asus Zenfone 4 ZE554KL - Guide To Unlock Bootloader Of Asus Zenfone 4 ZE554KLHere is the guide to Unlock Bootloader Of Asus Zenfone 4 ZE554KL. You can do most of the things by unlocking the bootloader. Asus Zenfone 4 ZE554KL Android phones released with locked bootloader and bloatware, so Zenfone 4 released with locked bootloader and bloatware. Afte unlocking the device, you can root the device also you can install Twrp Recovery.

Short Info About Asus Zenfone 4 ZE554KL:

The Zenfone 4 is having 5.5 HD screen. Having the 1080p resolution in this device. It has a display of pixel 1080by 1920. It Comes with the Qualcomm Snapdragon 630 processor. Packed with 4GB of ram. The Zenfone 4 is having storage 64GB internal. Expanded 256GB by using the external SD card. The camera of Asus Zenfone 4 is dual 12 megapixels at the rear. 8 megapixels at front. Runs on the Android 7.0 Nougat OS. It has the battery of 3300mAh capacity. Lasts up to 6-7 hours on continuous usage from a full charge. The smartphone has hybrid sim slots. The connectivity, has 4G, Bluetooth Wifi, OTG support. Zenfone 4 is packed with almost all sensors. Like Proximity sensor, Accelerometer, Ambient light sensor etc.

Preparation:-

  • Charge Your Device.
  • Backup Phone Apps, Contacts, SMS.
  • Enable developer options.

Go To Settings -> About Phone -> Tap On “Build Number” 7 Times To Enable Developer Options.

  • Enable USB Debugging.

Go To Your Settings -> Developer Options -> Tick The “Usb Debugging” Checkbox .

  • Enable OEM Unlock.

Go To Your Settings -> Developer Options -> Tick The“Oem Unlock” Check box

  • Install Asus Driver Link->.
  • Download “adb-fastboot-tool-2016.zip”.
  • Read Guide.



⇓⇓ Downloads ⇓⇓

adb-fastboot-tool-2016.zip

Also Read  Guide To Install Twrp Recovery and Root Letv Le 1S One Click Tool

Zenfone 4 Unlock Bootloader.zip

Recommended Posts:-



Guide To Unlock Bootloader Of Asus Zenfone 4 ZE554KL:-

1.) First Read Preparation, Unlock The Bootloader Download Required Files.

2.) Download “adb-fastboot-tool-2016.zip” and “Zenfone 4 Unlock Bootloader.zip“unzip it.

3.) Copy all Zenfone 4 Unlock Bootloader Folder Files To adb-fastboot-tool-2016 folder.

4.) Open cmd windows in adb-fastboot-tool-2016 folder by Shift + Mouse Right click.

adb fastboot cmd - Guide To Unlock Bootloader Of Asus Zenfone 4 ZE554KL

5.) Connect your phone to PC.

6.) Now paste this command on command window and hit enter to reboot your phone into bootloader (FASTBOOT) mode.

  • Or reboot into fastboot manually by (Volume Up + Power)

adb reboot-bootloader

7.) Now type the following codes below one by one. Press enter after entering each code. These codes are for Snapdragon 630 processor.

fastboot flash frp frp_unlock.bin

fastboot flash abl abl_630.elf

flastboot reboot-bootloader

fastboot flashing unlock

8.) Press enter after entering each code. These codes are for Snapdragon 660 processor.

fastboot flash frp frp_unlock.bin

fastboot flash abl abl_660.elf

flastboot reboot-bootloader

fastboot flashing unlock

Done now you have unlocked the Asus Zenfone 4 ZE554KL. If you like the post don’t forget to share it. Also, if you have any problem you can message us on our official Facebook page GIZDEV.
